The air sucked from the environment takes the ambient temperature values thanks to the exchanger and conditions the fresh air given. It provides cleaning of the ambient air and preventing heat loss.
Heat transfer is realized between the fresh air and exhaust air with the heat recovery ventilation devices, the heat energy lost during ventilation is recovered and the room temperature changes caused by the ventilation are regulated, thus ensuring a comfortable and clean environment continuously. In conventional ventilation systems, there are additional air conditioning loads coming from fresh air. In heat recovery devices, energy saving is achieved by reducing the load added on the air conditioning system.
E-IGK model heat recovery devices allow them to be mounted inside suspended ceilings due to their extremely low cabinet heights. They are mounted with hanger elements inside the suspended ceiling. Therefore, construction and metal profile bases are not required.
Another feature of the E-IGK model heat recovery units is that they can be used together in single split, multi split or variable refrigerant flow systems without fresh air delivery. E-IGK model heat recovery devices cover a wide range of applications with 10 different models (250-4000m3 / h).
Heat recovery devices have two different applications, horizontal and vertical. Cells are formed by extrusion method using an aluminum profile. The profile section has been specially selected for this job in order to facilitate assembly and increase strength.
Aluminum profiles are connected with aluminum or plastic corner pieces with increased strength, which are specially designed for this work. The use of these corner pieces brings the following advantages together.
