Rockwool Prefabricated Pipe

Rock Wool, Rubber Tubes, Insulating Materials

04.06.2020

352

It is a bare or aluminum foil coated rock wool pipe used in mechanical installation insulation. It is offered to the market in cardboard packages.

Product Features

Glasswool Prefabricated Pipe is selected according to the nominal diameter of the line to be applied. It is placed by opening from the cut area. The application should be completed so that there is no gap in the joints.
If two layers of application are made in the assembly of the pipes, care should be taken to avoid the joints, and care should be taken to ensure that the final layer joint is at the bottom of the pipe.
In this application, the joints of the two pipes should be closed with self-adhesive aluminum foil tapes of 7.5 cm width, thus preventing the passage of steam completely.

Technicial Specifications

Nominal Diameter Of The Pipe To Be İnsulated	Nominal Diameter Of The Pipe To Be İnsulated	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)
Inch	mm	25	30	40	50	60	80	100
1/4	13	+	+	+	+	+	+	+
1/2	21	+	+	+	+	+	+	+
3/4	27	+	+	+	+	+	+	+
1	33	+	+	+	+	+	+	+
11/4	42	+	+	+	+	+	+	+
11/2	48	+	+	+	+	+	+	+
2	60	+	+	+	+	+	+	+
21/2	76	+	+	+	+	+	+	+
3	89	+	+	+	+	+	+	+
4	114	+	+	+	+	+	+	+
5	140	+	+	+	+	+	+	+
6	169	+	+	+	+	+	+	+
8	219	+	+	+	+	+	+	+
10	273	+	+	+	+	+	+	+
12	324	+	+	+	+	+	+	+
14	356	+	+	+	+	+	+	+

Wondering About the Product

What are the areas of use?

It is used for heat saving and fire insulation in high temperature industrial and installation pipes. It is used for sound and vibration insulation in process equipment.

In what thickness is it available?

It is available in thicknesses of 25,30,40,50,60,80 and 100 mm.
