It is the connection apparatus that enables the installation of flexible ventilation ducts to the main ventilation ducts, distribution points. All kinds of fans and devices. Laboratory studies have shown that in existing applications the flexible duct can with stand up to 450 N when mounting with Exiva while stripping from the throat under a load of 50 – 100 N.
Diameter | Diameter | Ø d | Ø d | Ø D1 | Ø D1 | Ø D2 | Ø D2 | L | L | a | a |
---|---|---|---|---|---|---|---|---|---|---|---|
Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm | Inch | mm |
4 | Ø 102 | 3,54 | 90 | 4,49 | 114 | 3,66 | 93 | 4,61 | 117 | 2,05 | 52 |
5 | Ø 127 | 4,53 | 115 | 5,39 | 137 | 4,65 | 118 | 5,59 | 142 | 2,05 | 52 |
6 | Ø 152 | 5,51 | 140 | 6,38 | 162 | 5,63 | 143 | 6,61 | 168 | 2,05 | 52 |
8 | Ø 203 | 7,52 | 191 | 8,39 | 213 | 7,64 | 194 | 8,66 | 220 | 2,05 | 52 |
10 | Ø 254 | 9,53 | 242 | 10,39 | 264 | 9,65 | 245 | 10,71 | 272 | 2,05 | 52 |
Product Images
Product Features
- Provides more robust mounting in less time.
- Fewer equipment can be installed without problems even in confined spaces.
- By allowing maximum stretching of the flexible air duct, it prevents high pressure loss and accumulation of dust particles in the duct.
- Balancing can be done in the system with flaptypes
Technicial Specifications
Material | Polypropylene |
UL Standard | UL 2043 |
Temperature Resistance | -30 °C / 150 °C |
Diameter Range | Ø 102 mm – Ø 254 mm |
Standard Presentation Type | 48 piece/container |
Wondering About the Product
What is the standard form of presentation?
The standard form of presentation is box / 48 pieces.
What is the temperature resistance?
Temperature resistance is between -30 ° C and 150 ° C.
